Keor MOD
49
Installation and maintenance manual
KEOR MOD 250 – output cables installation with accessories for double cable
4.2.9 Battery cables installation
The default configuration has the strings of batteries in common.
Before the installation of the input cables, check the following:
- the fuse breakers of all the external battery cabinets must be open;
- the cables to connect to the UPS must be isolated upstream and no voltage must be present;
- the earthing cable from the low voltage switchgear must be properly connected (see paragraph 4.2.3).
WARNING
The neutral battery cable must always be connected.
