Lennox EL23XCV Series User Manual

Page 3
Specications
General
Data
Model No. - All Regions EL23XCV-024 EL23XCV-036 EL23XCV-048 EL23XCV-060
Nominal Tonnage
2345
Connections
(sweat)
Liquid line (o.d.) - in. 3/83/8 3/
83
/8
Suction line (o.d.) - in. 3/47/8 7/81-1/8
Refrigerant
1
R-410A charge furnished 7 lbs. 15 oz.8 lbs. 0 oz.11 lbs. 14 oz.11 lbs. 15 oz.
Compressor Type Rotary Rotary Rotary Scroll
Outdoor
Coil
Net face area - sq. ft. Outer coil 23.33 23.3327.21 27.21
Inner coil - - -- - -26.36 26.36
Tube diameter - in. 5/16 5/16 5/16 5/16
No. of rows
1122
Fins per inch 26 26 22 22
Outdoor
Fan
Diameter - in. 26 26 26 26
No. of blades
3333
Motor hp 1/31/3 1/
31
/3
Cfm - minimum speed 12701979 2997 2997
maximum speed 27864227 4212 4224
Rpm - minimum speed 467 367 618 618
maximum speed 756 838 911 939
Watts - minimum speed 22 25 85 85
maximum speed 68 182 230 245
Shipping Data - lbs. 1 pkg. 210 220 300 300
Electrical Data
Line Voltage Data - 60Hz 208/230V-1ph 208/230V-1ph 208/230V-1ph 208/230V-1ph
2
Maximum overcurrent protection (MOCP) amps 20 30 40 45
3
Minimum circuit ampacity (MCA) 12.6 19.2 23.6 27.4
Compressor Input (amps) 813.316.819.8
Outdoor Fan Motor - Full Load Amps 2.62.6 2.
62
.6
CONTROLS
S40 Smart Wi-Fi Thermostat (Communicating) 22V24
••••
⁴ Discharge Air Temperature Sensor 88K38
••••
E30 Smart Wi-Fi Thermostat 20A65
••••
Remote Outdoor Temperature Sensor X2658
••••
OPTIONAL ACCESSORIES - ORDER SEPARATELY
⁵ Freezestat 93G35
••••
50A93
••••
Refrigerant
Line Sets
L15-41-20 (20 ft.)
L15-41-30 (30 ft.)
L15-41-40 (40 ft.)
L15-41-50 (50 ft.)
89J56
89J57
89J58
89J59
•
L15-65-30 (30 ft.)
L15-65-40 (40 ft.)
L15-65-50 (50 ft.)
89J60
89J61
89J62
••
Field Fabricate •
NOTE - Extremes of operating range are plus 10% and minus 5% of line voltage.
1
additional refrigerant charge required.
2
HACR type breaker or fuse.
3
Refer to National or Canadian Electrical Code manual to determine wire, fuse and disconnect size requirements.
4
Used with the Lennox
®
S40 Smart Wi-Fi Thermostat for optional service diagnostics.
5
Freezestat is recommended for low ambient operation.
