Lennox EL23XCV Series User Manual

Page 4
Unit Dimensions – Inches (mm)
Model No.
A
in.mm
EL23XCV-024 39 991
EL23XCV-036 39 991
EL23XCV-048 45 1143
EL23XCV-060 45 1143
ELECTRICAL
INLETS
SIDE VIEW
DISCHARGE AIR
SUCTION LINE
CONNECTION
LIQUID LINE
CONNECTION
A
4-1/4(108)
4-3/4
(121)
1 (25)
2 (51)
END VIEW
TOP VIEW
SUCTION LINE
CONNECTION
LIQUID LINE
CONNECTION
TOP VIEW BASE SECTION
(Large Base)
UNIT SUPPORT
FEET
16-7/8
(429)
26-7/8
(683)
30-3/4 (781)
3-1/8
(79)
8-3/4
(222)
3-3/4 (95)
4-5/8
(117)
35-1/2 (902)39-/12 (1003)
11-5/8
(295)
