Typical Unit Parts Arrangement
CONTROL PANEL
EL23XCV-024, -036, -048
CONTROL PANEL
EL23XCV-060
OUTDOOR
CONTROL
INVERTER
REACTOR
DC INVERTER
CONTROL
GROUND LUG
CONTACTOR –
SPST
OUTDOOR
CONTROL
INVERTER
REACTOR
DC INVERTER
CONTROL
GROUND LUG
CONTACTOR –
SPST
FIGURE 1. Control Panel Components
