Page 53
Blower Data
EL196UH030XE24B AND EL196UH045XE24B PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1125 160 1015 125 935 105 830 65 905 70
0.10 1070 165 980 130 885 110 775 70 700 60
0.20 1035 175 950 140 845 115 715 75 560 50
0.30 1000 185 915 150 810 125 670 85 495 55
0.40 965 195 875 160 770 135 625 95 435 60
0.50 925 205 835 170 730 140 580 100 365 65
0.60 890 215 800 180 685 150 530 105 325 70
0.70 855 225 770 190 635 155 485 110 270 75
0.80 820 230 720 195 600 165 430 115 230 80
EL196UH045XE36B PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1460 335 1285 235 1190 170 910 85 870 75
0.10 1430 350 1260 245 1155 185 885 95 830 85
0.20 1405 365 1235 255 1125 200 860 105 800 90
0.30 1375 370 1205 265 1090 210 825 115 755 95
0.40 1350 380 1175 275 1055 215 780 125 710 105
0.50 1315 385 1145 285 1020 230 735 130 665 115
0.60 1245 375 1110 295 980 240 685 140 620 125
0.70 N/A N/A 1070 305 940 250 640 145 575 135
0.80 N/A N/A 1020 310 905 260 600 155 530 140
EL196UH070XE36B PERFORMANCE (Less Filter)
External
Static
Pressure
in. w.g.
Air Volume / Watts at Various Blower Speeds
High Medium-High Medium Medium-Low Low
cfm Watts cfm Watts cfm Watts cfm Watts cfm Watts
0.00 1445 315 1315 215 1215 165 930 85 925 75
0.10 1445 335 1275 230 1170 180 905 94 860 80
0.20 1415 345 1240 240 1125 190 870 101 800 85
0.30 1380 355 1205 250 1090 200 830 109 760 95
0.40 1345 370 1175 265 1055 210 790 117 710 105
0.50 1315 385 1150 280 1020 220 735 129 665 115
0.60 1275 390 1110 290 985 230 685 137 625 125
0.70 1210 395 1075 300 950 240 640 146 565 130
0.80 N/A N/A 1030 305 915 250 595 148 535 135
