Lennox Elite series Installation Instructions

2
Table of Contents
Shipping and Packing List 2.....................
Description 3..................................
Dimensions (H x W x D) 3......................
Wall Plate Dimensions (H x W) 3.................
Compressor Short Cycle Protection 3.............
Installation 4..................................
Installation Setup 4............................
Wiring thermostat 8............................
Installer Settings 10.............................
Menu 10.......................................
System Setup 11...............................
Residual Cool 11...............................
Deadband 11..................................
Smooth Set Recovery (SSR) 11..................
Dealer Information 11...........................
Stage 1 Diff 11.................................
Temperature Offset 11..........................
Compressor Protect 11..........................
Custom Reminders 12...........................
Reset Settings 12...............................
Energy saving Default 12........................
System Test Modes 12..........................
Unit Part (Catalog) & Serial Numbers 13...........
Memory Protection 13...........................
Diagnostic Information 14........................
Reminder Information 15.........................
Supported Configurations 15.....................
Installation Checklist 16..........................
Shipping and Packing List
1 - ComfortSense
®
5500 touchscreen, 7-day pro
grammable thermostat with back plate
1 - Wall plate
2 - Mounting screws (M3.5x25mm self-tapping
screws)
2 - Wall anchors
1 - Warranty certificate
1 each - Homeowner and Installer Guides
NOTE - This thermostat is equipped with automatic
compressor protection to prevent potential damage
due to short cycling or extended power outages.
The short cycle protection provides a 5-minute
delay between heating or cooling cycles to prevent
the compressor from being damaged.
IMPORTANT
Read this manual before programming the ther
mostat.
Use this thermostat only as described in this man
ual.
Description
The ComfortSense
®
5500 thermostat (Catalog No.
13H13) is an electronic 7-day single‐stage program
mable touch screen thermostat. It also offers en
hanced capabilities which include:
S worry-free memory storage feature
