7
Technical Information
Service Manual
W
D
H
131 542 172
43
43
80
143
Ф5 5
Ф5 5
181685104
Ф55
Ф55
190
181
38
38
90
150
54
168.5 462 159.5
Φ55
Φ55
54
206
685
187
Ф70
Ф70
4343
154 79
3. Outline Dimension Diagram
3.1 Indoor Unit
Unit:mm
LM009CI-100T432-1
LM012CI-100T432-1
LM018CI-100T432-1
LM024CI-100T432-1
Model W H D
LM009CI-100T432-1 790 275 200
LM012CI-100T432-1 845 289 209
1LM018CI-100T432-1 970 300 224
1LM024CI-100T432-1 1078 325 246
