26
Installation and Maintenance
Service Manual
8. Installation
8.1 Installation Dimension Diagram
Drainage pipe
At least250cm
At least 15cm
At least 50cm
At least 50cm
At least
30cm
At least 300cm
At least 200cm
Spacetothe
Space to the obstruction
Space to the o
bstruction
Space to the
obstruction
Spacetothe ceiling
Space to the obstruction
Space to the obstruction
At least 30cm
At least15cm
At least 15cm
Space to the wall
Spacetothe wall
Space to the wall
