Technical Information
Service Manual
Model
LM009CI-100T432-1
LM009CO-100T432-1
LM012CI-100T432-1
LM012CO-100T432-1
Product Code Y6760 Y6761 Y6762 Y6763
Power
Supply
Rated Voltage V~ 220-240 220-240
Rated Frequency Hz 50 50
Phases 1 1
Power Supply Mode Indoor Indoor
Cooling Capacity Btu/h 9000 12000
Heating Capacity Btu/h / /
Cooling Power Input W 819 1134
Heating Power Input W / /
Cooling Power Current A 3.22 5.03
Heating Power Current A / /
Rated Input W 1130 1300
Rated Current A 6.85 7.0
Air Flow Volume(SH/H/M/L/SL) m
3
/h 550/490/430/370/- 630/540/460/330/-
Dehumidifying Volume L/h 0.8 1.4
EER (Btu/h)/W 10.99 10.58
COP (Btu/h)/W / /
SEER W/W / /
HSPF W/W / /
Application Area m
2
12-18 16-24
Indoor Unit
Model of indoor unit LM009CI-100T432-1 LM012CI-100T432-1
Indoor Unit Product Code Y6760 Y6762
Fan Type Cross-ow Cross-ow
Diameter Length(DXL) mm Ф98X580 Ф98X633.5
Fan Motor Cooling Speed(SH/H/M/L/SL) r/min 1350/1200/1050/800/- 1350/1200/1050/850/-
Fan Motor Heating Speed(SH/H/M/L/SL) r/min / /
Output of Fan Motor W 20 20
Fan Motor RLA A 0.2 0.32
Fan Motor Capacitor μF 1 1.5
Evaporator Form Aluminum Fin-copper Tube Aluminum Fin-copper Tube
Pipe Diameter mm Ф5 Ф5
Row-n Gap mm 2-1.4 2-1.4
Coil Length (LXDXW) mm 584X22.8X266.7 635X25.4X304.8
Swing Motor Model MP24AA MP24BA
Output of Swing Motor W 1.5 1.5
Fuse A 3.15 3.15
Sound Pressure Level (SH/H/M/L/SL) dB (A) 39/36/32/26/- 42/38/33/29/-
Sound Power Level (SH/H/M/L/SL) dB (A) 49/46/42/36/- 52/48/43/39/-
Dimension (WXHXD) mm 790X275X200 845X289X209
Dimension of Carton Box (LXWXH) mm 863X268X352 918X278X364
Dimension of Package (LXWXH) mm 866X271X367 921X281X379
Net Weight kg 9 10.5
Gross Weight kg 11 12.5
2. Specications
2.1 Specication Sheet

Lennox LM009CI-100T432-1 Specifications

General

Brand	Lennox
Model	LM009CI-100T432-1
Category	Air Conditioner
Language	English
