17
Multiple Thermostats - Group ID
Multiple S40 thermostats in a home can be assigned to a group (up to nine
groups with up to ve (5) thermostats in each group). All thermostats in a group
can communicate with other thermostats in the same group over a single 2.4
GHz Wi-Fi network.
IMPORTANT
If the home will have multiple S40 thermostats then they all MUST be on the
same 2.4GHz Home Wi-Fi network in order to communicate with each other.
Do not use 5 GHz.
All S40 thermostats can be grouped together. If you have a S30 or E30, they
will NOT be appear on the S40 thermostat.
Default Group ID 1. Range is 1 to 9.
NOTE: If a thermostat is set to Group 0, then there is no connectivity with
another S40 thermostat within the home on the same 2.4Ghz Wi-Fi
network.
Group IDs can be changed by going to Settings > Advanced Settings > View
Support Service Control Center > Equipment Settings > Thermostat and
look for Group ID.
Restarting thermostat
To restart the thermostat, go to > Settings > Advanced Settings > View
Support Service Control Center > Equipment Settings > Reset > Restart
Thermostat.
Commissioning Using the Thermostat
The following procedures are written for commissioning the system using
the Thermostat interface. When power is rst applied to the system all
communicating devices attached to the system (air handler or furnace, outdoor
unit, PureAir S or zoning control) will automatically be congured using optimal
factory default settings based on system type, capacity and other conguration
considerations.
NOTE: If there is a PureAir S Air Purication System installed, during
commissioning the blower will turn on and run at three different CFM
settings for the PCO lter calibration to take place. This may be well
in advance before the display is fully up and running. This is a normal
process. The blower may run as long as ninety (90) seconds at each
CFM setting to complete the lter calibration.
1. Apply power to the thermostat.
IMPORTANT
If after applying power to the thermostat a “System Under Test” screen appears,
it could indicate either the system is under reconguration or is unable to
communicate with the indoor unit. Check wiring connections between the
thermostat wall plate and indoor unit for loose or incorrect connections.
2. A Welcome screen will appear. Select the desired language to be used.
Options are English, Franҫais and Español. Select the right arrow to
continue.
3. On the Choose Setup Route screen there are three options:
» Continue setup process through the thermostat
» Continue setup process through the mobile app
Select option 1 and select the right arrow to continue.
Dealer Information
IMPORTANT
Enter dealer ID number. If not available, enter phone number associated
with the dealer account. This will the enable ability to perform advanced
diagnostics and remote sharing if permitted by homeowner.
This screen in the commissioning sequence is the dealer service center screen
where the dealer ID and/or phone number can be added. Once the system
is connected to the Internet, the remaining information will be populated
automatically by the Lennox server based on the dealer name or phone
number entered. All information can be entered manually if desired however.
Information that can be manually entered is name, email website, dealer
address which includes address 1, address 2, city, state and zip/postal code.
Once completed touch continue.
General Settings
On this screen general information needs to be veried or changed. Touch
any item to change its contents. A pop-up screen will appear that will allow the
information to be added or changed.
1. Select country / region.
2. Select time and date which includes time, date, time zone and daylight
savings time (ON/OFF).
3. Select temperature unit (Fahrenheit or Celsius).
4. Once completed touch the right arrow.
