Lennox S40 Installation And Setup Guide

38
Lennox Wireless Extender
Table 15. Lennox Wireless Extender
Parameter Description
Extender Name
This could be the default extender name given when the device
was added. This eld also allows the extender to be renamed.
Device Type Extender
Monitor Status
RSSI Signal Strength
This indicates the Bluetooth signal strength between the monitor
and the S40 thermostat or wireless extender if used.
Extender Information
Model Number Model number of device.
Serial Number Serial number.
Firmware Version Current rmware version of the sensor.
Reset
Table 16. Reset
Parameter Description
Restart thermostat Restarts the thermostat.
Re-congure
System
Re-congure HVAC system.
Reset HVAC
Equipment
Resets all HVAC equipment.
Factory Reset
Thermostat
Resets thermostat to factory default settings.
Factory Reset
thermostat
Resets thermostat parameters back to factory default.
Information
The dealer information screen will appear. The next screen will be for dealer
information. Here either the dealer ID or phone number can be added. Once the
system is connected to the Internet, the remaining information is automatically
populated. Not all information for this screen will be viewable. Touch and hold
and then drag up to access the remaining information on the screen.
Information Required: Dealer ID and / or dealer phone number. Information
that can be manually entered is name, email website, dealer address which
includes address 1, address 2, city state and zip/postal code. Once completed,
touch the left arrow at the top left side of screen to return to the Dealer Control
Center.
IMPORTANT
Adding dealer information will ensure the thermostat is associated with your
LennoxPros account when connecting to the Lennox server.
Information Pop-Up Screen: If the dealer ID or phone number is not provided,
a warning screen will appear. The warning screen will provided information on
the limitation imposed on the system if this information is missing. Touch no to
return to the above screen to complete the information requested or press yes
to continue.
Tests
Verify Airow Per Zone is the rst screen to appear under this selection. If
no zoning is installed then this screen will not appear during commissioning.
If zoning equipment is detected by the system then zones 1 through 4 will
be listed. These screens allow for verication and modication of CFMs for
blower, heating and cooling circulation. Touch continue to proceed to the next
screen.
Select Test Mode is the next screen to appear. Your options are automated
tests or manual tests. Select the desired option and select apply.
• Automated Tests: Select this options and the next screen will allow you to
select the specic tests available for your hardware conguration. The test
are automatic and no installer / service technician’s attendance is required.
When the automatic testing is complete the system returns to the consumer
home screen. A updated installation report is generated and available in
Lennox Pros under the Homeowners account.
• Manual Test: Depending on hardware present, various tests are available.
By default all items to be tested are enabled. Selecting a specic test will un-
check the item. When a specic set of tests are completed the results will be
displayed on the screen next to the tested item. Touch continue to proceed to
the next set of test items. Once all tests are completed press done to return
