Lennox S40 Installation And Setup Guide

46
Alert Codes
Table 21. Lennox S40 Smart Thermostat Alert Codes and Troubleshooting
E2A=Errors to Action, GF= Gas Furnace, AH=Air Handler, IU=Indoor unit (GF or AH), HP=Heat Pump, AC=Air Conditioner, OU=Outdoor Unit (AC or HP), PA=Pure Air S, ZA=Zone system,
SRS=Smart Room Sensor, TS=Thermostat , IAQ- IAQ Monitor and WE=Wi-Fi Extender
Alert
Code
Inverter
Flash
Code
Priority
Condition
Actual Displayed Alert
Text Under dealer control
center > Notications
Component or System Operational State and Troubleshooting Tip
How to clear
alert code
10
Service
Urgent
Unknown Device
Detected
The thermostat when NOT in conguration mode has detected an unknown device. Typically the thermostat
will send a command to the unknown device and place the device into a soft disable state. The soft disable
control will indicate so as follows:
• On air handler, furnace and outdoor controls, the soft-disabled state is displayed by double horizontal lines
on seven-segment display.
• On the damper control module, the green LED will ash 3 seconds on and 1 second off.
• On the equipment interface module, the green LED will ash 3 seconds on and 1 second off.
• A new communicating device has been added to the system since the original conguration setup was
completed.
• Go to Menu > Settings > Advanced Settings > View Support Service Control Center > Equipment
Listing > Reset and select Reset All Equipment. This will allow the system to auto-detect any Lennox
communicating devices attached.
Clear alert code by
reconguring the
system.
11
Service
Urgent
Missing Device
The thermostat cannot nd a previously installed system component.
• Check all system components (devices) connections to make sure they are Lennox communicating
compatible.
• Cycle system power.
• If problem persists, then check all system components (devices) connections to make sure they are
Lennox communicating compatible.
• Go to Go to Menu > Settings > Advanced Settings > View Support Service Control Center >
Equipment Listing > Reset and select Reset All Equipment. This will allow the system to auto-detect
any Lennox communicating components attached.
Cycle system power,
and If problem
persists then clear
by reconguring the
system.
12
Service
Urgent
Indoor Unit Not
Detected
Thermostat did not nd an indoor unit. Make sure there is an Lennox communicating indoor unit on the
system.
• Check for voltage and missing component.
• Check R, i+, i- and C connections at mag-mount or subbase, thermostat and all attached communicating
components.
• Ohm wires for electrical continuity.
• Cycle power to both indoor unit rst and then thermostat.
• Verify that equipment interface module (if applicable) is congured as either an air handler or furnace when
used with a non-communicating indoor unit.
• Go to Go to Menu > Settings > Advanced Settings > View Support Service Control Center >
Equipment Listing > Reset and select Reset All Equipment. This will allow the system to auto-detect
any Lennox communicating components attached.
• Replace indoor unit control if there is no response.
Automatically clears
when the system
detects that the issue
no longer exists.
