10.Installthescrewtosecurethecardreaderbrackettothechassis.
Figure22.Installingthescrewthatsecuresthecardreader
11.ReconnectthecardreadercabletooneoftheUSBconnectorsonthesystemboard.See“Locating
partsonthesystemboard”onpage11
.
12.Pivottheopticaldrivebaydownwarduntilitsnapsintoposition.
13.Reinstallthefrontbezel.See“Removingandreinstallingthefrontbezel”onpage32.
Whattodonext:
•Toworkwithanotherpieceofhardware,gototheappropriatesection.
•Tocompletetheinstallationorreplacement,goto“Completingthepartsreplacement”onpage87
.
InstallingorreplacingthemSATAsolidstatedrive
Attention:
Donotopenyourcomputerorattemptanyrepairbeforereadingandunderstandingthe“Importantsafetyinformation”
onpagev.
ThissectionprovidesinstructionsonhowtoinstallorreplacethemSATAsolidstatedrive.
Note:ThemSATAsolidstatedriveisonlyavailableinsomemodels.Fornewinstallation,see“Installing
themSATAsolidstatedrive”onpage44.Forreplacement,see“ReplacingthemSATAsolidstatedrive”
onpage47.
InstallingthemSATAsolidstatedrive
ToinstallthemSATAsolidstatedrive,dothefollowing:
44ThinkCentreUserGuide
