Connecting input devices
Attention: Be sure to disconnect all power to the projector and connecting devices before making
connections.
A PC or notebook computer as well as video devices can be connected to the projector at the same time.
Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still
cameras. Check the user manual of the connecting device to confirm it has the appropriate output
connector.
A B C D
Connecting devices Description
AUSB Connect the supplied USB cable from a computer.
BAudio-in Connect the supplied audio cable (mini jack-to-RCA x 2) from a video
device. Connect an audio cable (not supplied) from the computer’s
audio-out connector.
CVideo/S-video Connect the supplied composite video cable from a video device.
Connect the supplied S-video cable from a video device
DDVI-I Connect the supplied computer cable from a computer.
Connect a component video cable (not supplied) from a video device.
Connecting to a USB device
To control your computer mouse using the projector remote control, connect the projector to the computer
with a USB cable as shown below.
Note: USB mouse function is only supported with Windows 2000 and Windows XP.
2-2 M500 Projector User’s Guide
