Overview 5
Rear view
Note
Your computer model might look slightly different from the illustration.
1
Integrated camera shield control slider (optional)
Used to block the integrated camera.
2
Security-lock slot
Used to secure a Kensington-style cable lock.
3
USB 3.0 connectors (4)
Used to connect a USB-compatible device, such as a
USB keyboard, mouse, scanner, printer, or personal digital
assistant (PDA). For optimal data transfer, connect a USB
3.0 device to a USB 3.0 connector instead of a USB 2.0
connector.
4
DisplayPort®-out connector
Used to connect a high-performance monitor, a direct-drive
monitor, or other devices that use a DisplayPort connector.
5
Ethernet connector
Used to connect an Ethernet cable for network access.
6
Serial connector (optional)
Used to connect an external modem, a serial printer, or
other devices that use a 9-pin serial connector.
7
Power cord connector
Used to connect the power cord to your computer for
power supply.
