Lenovo ThinkPad T410s 2901 User Manual

1100 Palm rest or palm rest with fingerprint reader
For access, remove these FRUs in order:
v “1010 Battery pack” on page 85
v “1030 Solid state drive (SSD) or hard disk drive (HDD)” on page 87
v “1070 Keyboard” on page 98
Table 19. Removal steps of palm rest or palm rest with fingerprint reader
2
2
1
1
1
1
1
1
1
1
Step Screw (quantity) Color Torque
1 M2 × 4 mm, bind-head, nylon-coated (8) Black 0.181 Nm
(1.85 kgfcm)
2 M2 × 6 mm, bind-head, nylon-coated (2) Black 0.181 Nm
(1.85 kgfcm)
Note:
In models with the fingerprint reader, the sensor is attached to the palm rest
FRU. If the fingerprint reader has any defects, you can replace it by the
procedures given in this section, which are the same for a palm rest with or
without a fingerprint reader.
106 ThinkPad T400s, T410s, and T410si Hardware Maintenance Manual

Lenovo ThinkPad T410s 2901 Specifications

General

Graphics	Intel HD Graphics
Battery	6-cell Li-Ion
Processor	Intel Core i5-520M
Display	14.1 inch, 1440 x 900 pixels
RAM	Up to 8GB DDR3
Storage	128GB SSD
Operating System	Windows 7 Professional
Weight	1.77 kg (3.9 lbs)
Ports	3 x USB 2.0, VGA, DisplayPort, Ethernet
Wireless	Bluetooth 2.1
