Lenovo ThinkPad T410s 2901 User Manual

2050 LCD panel
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 85
v “2010 LCD bezel assembly” on page 130
Important notice on handling the LCD panel:
The LCD panel and the peripheral parts used in this product are very sensitive.
Improper handling of the LCD panel can cause damage to the parts, and may
cause a system malfunction such as a missing dot, missing line, or pixel
problems.
v DO NOT apply any kind of pressure to the LCD panel.
v When you lift the LCD panel, always hold the left and right edges of the
panel with both of your hands. DO NOT hold the panel with one hand or
hold the top and bottom edges of the panel.
v DO NOT touch or apply any kind of pressure to the print circuit board or
sensitive parts as shown in the figure a.
a
Removing and replacing a FRU 137

Lenovo ThinkPad T410s 2901 Specifications

General

Graphics	Intel HD Graphics
Battery	6-cell Li-Ion
Processor	Intel Core i5-520M
Display	14.1 inch, 1440 x 900 pixels
RAM	Up to 8GB DDR3
Storage	128GB SSD
Operating System	Windows 7 Professional
Weight	1.77 kg (3.9 lbs)
Ports	3 x USB 2.0, VGA, DisplayPort, Ethernet
Wireless	Bluetooth 2.1
