Lenovo ThinkPad T410s 2901 User Manual

2080 LED cable
For access, remove these FRUs in order:
v “1010 Battery pack” on page 85
v “1020 Serial Ultrabay Slim device or travel bezel” on page 86
v “1030 Solid state drive (SSD) or hard disk drive (HDD)” on page 87
v “1050 PCI Express Mini Card for wireless LAN” on page 92
v “1060 PCI Express Mini Card for wireless WAN” on page 95
v “1070 Keyboard” on page 98
v “1090 Wireless USB adapter or Intel Turbo Memory” on page 104
v “1100 Palm rest or palm rest with fingerprint reader” on page 106
v “1120 Keyboard bezel and speaker assembly” on page 109
v “1150 LCD unit” on page 116
v “2010 LCD bezel assembly” on page 130
v “2050 LCD panel” on page 137
v “2060 LCD cable” on page 140
v “2070 Hinge kit” on page 141
Table 34. Removal steps of LED cable
1
1
Removing and replacing a FRU 143

Lenovo ThinkPad T410s 2901 Specifications

General

Graphics	Intel HD Graphics
Battery	6-cell Li-Ion
Processor	Intel Core i5-520M
Display	14.1 inch, 1440 x 900 pixels
RAM	Up to 8GB DDR3
Storage	128GB SSD
Operating System	Windows 7 Professional
Weight	1.77 kg (3.9 lbs)
Ports	3 x USB 2.0, VGA, DisplayPort, Ethernet
Wireless	Bluetooth 2.1
