Parts list
This chapter contains following lists of the service parts.
v “Overall” on page 152
v “LCD FRUs” on page 171
v “Keyboard” on page 183
v “Miscellaneous parts” on page 184
v “AC adapters” on page 187
v “Power cords” on page 188
v “Recovery discs” on page 189
v “Common service tools” on page 204
Notes:
v Each FRU is available for all types or models, unless specific types or models
are specified.
v FRU with specific models listed and described as xxU (where U is an example
of a country designator) should be used for all models ending in U.
v FRU with specific models listed and described as 3Dx (where 3D is an
example of a unique configuration) should be used for all of these models,
unless specific country or region designator is specified.
v A CRU (customer replaceable unit) is identified by a single asterisk (*) or two
asterisks (**) in the CRU ID column. An N in the CRU ID column means that
the part is not a CRU. A single asterisk (*) means that the part is a Self-service
CRU; two asterisks (**) means that the part is an Optional-service CRU.
ThinkPad Notebooks contain the following types of CRUs:
Self-service CRUs
These CRUs unplug or are held by no more than two screws.
Examples of these types of CRUs include an AC adapter, a power
cord, a battery, and a hard disk drive. Other Self-service CRUs
depending on product design may include a memory, a wireless card,
a keyboard, and a palm rest with finger print reader and touchpad.
Optional-service CRUs
These CRUs are isolated parts within the computer that are concealed
by an access panel that is typically secured by more than two screws.
Once the access panel is removed, the specific CRU is visible.
v FRUs marked with OP are available as options.
© Copyright Lenovo 2009, 2010 151
