Lenovo ThinkPad T410s 2901 User Manual

1020 Serial Ultrabay Slim device or travel bezel
For access, remove this FRU:
v “1010 Battery pack” on page 85
Table 10. Removal steps of Serial Ultrabay Slim device or travel bezel
Holding the bay lock latch in the unlocked position 1, slide the bay eject latch
2, and then pull out the Ultrabay Slim Media Bay device or the travel bezel in
the direction shown by arrow 3.
3
2
1
4
86 ThinkPad T400s, T410s, and T410si Hardware Maintenance Manual

Lenovo ThinkPad T410s 2901 Specifications

General

Graphics	Intel HD Graphics
Battery	6-cell Li-Ion
Processor	Intel Core i5-520M
Display	14.1 inch, 1440 x 900 pixels
RAM	Up to 8GB DDR3
Storage	128GB SSD
Operating System	Windows 7 Professional
Weight	1.77 kg (3.9 lbs)
Ports	3 x USB 2.0, VGA, DisplayPort, Ethernet
Wireless	Bluetooth 2.1
