22 Information BM3
6 Installing and connecting the BM3 module
6.1 The BM3 connections
C
2
1
2b
2a
T
O
Figure 1
Driving section connection
Stopping section connection
Signal light GREEN (Clear)
Joint connection for signal lights
Signal light RED (Stop)
Track connections of the amplifier
Outputs for connecting feedback
modules LR101
Signal output / Signal input
