26 Information BM3
6.6.2 Connecting signals with double-coil drives (form signals)
Form signals cannot be connected directly to the BM3 signal output. The BMA adapter (art. no.
22630) is available for this purpose. For more detailed information, please refer to the BMA adapter
operating manual.
7 Tips for use
7.1 Using the BM2 at the end of a block section
You can use the BM2 module to complete a block section of BM3 modules. In a typical case, the
entry signal to a station would be at the end of a block section. By setting the entry signal, you, as
the conductor, determine whether an arriving train may or may not enter the station.
