Lenze EVS9324EP User Manual

Function library
Function blocks
3.5.65 Variable table − acceleration (VTACC)
3−274
l
EDSVS9332P−EXT DE 2.0
Function
A total of 34 table positions is available.
l Enter fixed values under C1303.
– 30 table positions (VTACC−No1 ... VTACC−No30) are available.
– Subcodes (C1303/1 ... C1303/30) define the table position number.
l Enter variable values in VTACC−INx.
– 4 table positions (VTACC−No31 ... VTACC−No34) are available.
– Signal input via function blocks.
– The values must be transmitted to the table positions before the corresponding program set
starts and accesses these values.
l C1384 indicates the values (in % of amax) on the table positions.
– Select table position (C1384/1 ... C1384/34) with subcode.
l C1385 displays the values (in inc) on the table positions.
– Select table position (C1385/1 ... C1385/34) with subcode.
l The conversion from a [units/s
2
] to a [inc] is performed according to the
formula:
a[inc] + a[unitsńs
2
] @
65536[incńr] @ gearnominator @ 16384
Feedconst.[unitsńr] @ geardenominator @ 1000000[1ńs
2
]
Tip!
Entries into the processing table are only required if FB inputs and outputs are used.
