3.3 Table of free control codes
Free control codes can be used for the selection of setpoints or as variables. The codes can be
connected with inputs of function blocks.
Designation Signal type Code Connection to the function block in
the Lenze setting
Note
FCODE−17 a C0017 −
FCODE−26/1 a C0026/1 AIN1−OFFSET
FCODE−26/2 a C0026/2 AIN2−OFFSET
FCODE−27/1 a C0027/1 AIN1−GAIN
FCODE−27/2 a C0027/2 AIN2−GAIN
FCODE−32 a C0032 −
FCODE−37 a C0037 −
FCODE−108/1 a C0108/1 AOUT1−GAIN
FCODE−108/2 a C0108/2 AOUT2−GAIN
FCODE−109/1 a C0109/1 AOUT1−OFFSET
FCODE−109/2 a C0109/2 AOUT2−OFFSET
FCODE−141 a C0141 −
FCODE−1211 a C1211 POS−START−PS
FCODE−472/1 a C0472/1 −
FCODE−472/2 a C0472/2 −
FCODE−472/3 a C0472/3 ANEG1−IN
MCTRL−HI−M−LIM
FCODE−472/4 a C0472/4 −
FCODE−472/5 a C0472/5 −
FCODE−472/6 a C0472/6 MCTRL−PHI−LIM
FCODE−472/7 a C0472/7 −
FCODE−472/8 a C0472/8 −
FCODE−472/9 a C0472/9 −
FCODE−472/10 a C0472/10 −
FCODE−472/11 a C0472/11 −
FCODE−472/12 a C0472/12 −
FCODE−472/13 a C0472/13 −
FCODE−472/14 a C0472/14 −
FCODE−472/15 a C0472/15 −
FCODE−472/16 a C0472/16 −
FCODE−472/17 a C0472/17 −
FCODE−472/18 a C0472/18 −
FCODE−472/19 a C0472/19 −
FCODE−472/20 a C0472/20 −
FCODE−473/1 a C0473/1 −
FCODE−473/2 a C0473/2 −
FCODE−473/3 a C0473/3 −
FCODE−473/4 a C0473/4 −
FCODE−473/5 a C0473/5 −
FCODE−473/6 a C0473/6 −
FCODE−473/7 a C0473/7 −
FCODE−473/8 a C0473/8 −
FCODE−473/9 a C0473/9 −
FCODE−473/10 a C0473/10 −
FCODE−250 d C0250 −
FCODE−471.B0 d C0471 −
FCODE−471.B1 d C0471 POS−S−RAMPS
FCODE−471.B2 d C0471 −
FCODE−471.B3 d C0471 −
