Lenze g500-H User Manual

Geared motors 600 Nm to 3000 Nm
Gearboxes g500-H600 g500-H850 g500-H1500 g500-H3000
Min. motor assignment MF□MA□□063 MF□MA□□063 MF□MA□□063 MF□MA□□063
Max. motor assignment MF□MA□□132 MF□MA□□132 MF□MA□□132 MF□MA□□132
Technical data
Max. output torque Nm 600 850 1500 3000
Min. drive power kW 0.55 0.55 0.55 0.55
Max. drive power kW 22 22 22 22
Mounng posion
Standard M1/M2/M3/M4/M5/M6 (ABCDEF)
Combined -
Color Primed
Painted in RAL colors
Surface and corrosion protecon OKS-S
Dierent types of OKS
Output sha
Solid sha with featherkey mm 35 x 70
40 x 80
40 x 80 50 x 100 60 x 120
Solid sha without keyway mm 35 x 70 40 x 80 50 x 100 60 x 120
Sha material Steel
Stainless steel
Output sha bearing Standard
Reinforced
Gearbox design With foot (VBR)
With foot and centering (VAR)
With foot and output ange (VAK)
With centering (VCR)
With output ange (VCK)
Output ange mm 200/250 250/300 250/300/350 300/350/450
Venlaon Vent valve
- Oil compensaon reservoir
Cooling Integral fan
Blower
Product extensions
Connecon method Y/Δ
Connecon type Terminal box
ICN connector
HAN connector
M12 connector
Spring-applied brake Without
With
Feedback Without
Resolver
Incremental encoder
Absolute value encoder
Temperature monitoring TKO thermal contact
PT1000 temperature sensor
PTC thermistor
Product informaon
The modular system
11
