Connecon via HAN connector
Posion of the connecons
1
Note Meaning
1 Power connecon
Brake connecon
PE connecon
Connecon of temperature monitoring
Addionally for HAN-Modular:
•
Recer connecon
HAN 10E connector
The motor connecon is specied in the counter plug.
The connector is only suitable for motors with the connecon method Y/Δ.
HAN 10E connector assignment
1
2
3
4
5
6
7
8 9
10
Bridge arrangement in the HAN 10E mang connector
Contact Name Meaning
6-7-8 Y Connecon
1-6
2-7
3-8
Δ
HAN 10 E
Contact Name Meaning
1 U1
Motor winding phase2 V1
3 W1
4 +/AC
Brake
5 -/AC
6 W2
Motor winding phase7 U2
8 V2
9 TKO/+PT1000
Temperature monitoring
10 TKO/-PT1000
Product extensions
Motor connecon
Connecon via HAN connector
138
