Lenze g500-H User Manual

120 Hz: 18.5 kW
Inverter operaon Geared motor
5 Hz - - 20 Hz - 120 Hz (1:24)
n
22
M
22
n
21
M
2
n
2
M
2
c J i z m
rpm Nm rpm Nm rpm Nm kgcm² kg
46.1 97.1 191 151 1131 151 1.5 350.097 3.147 g500-H850 MFXMA 132-22 2 97
44.4 101 184 157 1090 157 1.1 342.900 3.267 g500-H600 MFXMA 132-22 2 89
42.1 106 174 166 1034 166 1.2 340.943 3.444 g500-H450 MFXMA 132-22 2 77
38.7 116 160 180 951 180 3.2 373.796 3.743 g500-H1500 MFXMA 132-22 2 128
33.2 135 138 210 816 210 1.4 344.786 4.362 g500-H850 MFXMA 132-22 2 97
32.4 138 134 216 795 216 1.0 340.253 4.480 g500-H600 MFXMA 132-22 2 89
30.7 146 127 227 754 227 1.0 339.213 4.724 g500-H450 MFXMA 132-22 2 77
30.5 147 126 229 748 229 3.0 363.688 4.758 g500-H1500 MFXMA 132-22 2 128
27.0 166 112 258 663 258 1.3 342.388 5.368 g500-H850 MFXMA 132-22 2 97
25.3 177 105 276 621 276 0.9 338.866 5.733 g500-H600 MFXMA 132-22 2 89
24.4 183 101 286 599 286 1.4 346.432 5.946 g500-H850 MFXMA 132-22 2 97
24.0 187 99.2 291 589 291 0.8 338.231 6.045 g500-H450 MFXMA 132-22 2 77
23.2 193 96.1 301 570 301 2.7 354.863 6.245 g500-H1500 MFXMA 132-22 2 128
22.5 199 92.9 311 552 311 1.0 340.444 6.456 g500-H600 MFXMA 132-22 2 89
19.1 234 79.0 365 469 365 2.5 359.724 7.592 g500-H1500 MFXMA 132-22 2 128
17.6 254 72.8 397 432 397 1.2 342.878 8.241 g500-H850 MFXMA 132-22 2 97
16.4 273 67.8 426 402 426 0.9 338.947 8.853 g500-H600 MFXMA 132-22 2 89
14.3 313 59.2 488 351 488 1.0 341.129 10.143 g500-H850 MFXMA 132-22 2 97
12.8 350 52.8 546 314 546 1.9 348.806 11.356 g500-H1500 MFXMA 132-22 2 128
12.8 351 52.8 547 313 547 1.0 340.223 11.360 g500-H850 MFXMA 132-22 2 97
12.5 359 51.6 559 306 559 3.2 366.315 11.619 g500-H3000 MFXMA 132-22 2 169
10.6 422 43.9 658 260 658 1.6 346.063 13.673 g500-H1500 MFXMA 132-22 2 128
10.2 439 42.2 685 250 685 2.8 359.535 14.233 g500-H3000 MFXMA 132-22 2 169
10.0 447 41.4 697 246 697 0.8 339.061 14.490 g500-H850 MFXMA 132-22 2 97
8.7 517 35.8 807 212 807 1.4 343.834 16.763 g500-H1500 MFXMA 132-22 2 128
7.7 579 32.0 902 190 902 2.3 351.200 18.752 g500-H3000 MFXMA 132-22 2 169
6.4 701 26.4 1093 157 1093 1.0 340.766 22.711 g500-H1500 MFXMA 132-22 2 128
6.3 711 26.0 1109 155 1109 2.0 347.350 23.044 g500-H3000 MFXMA 132-22 2 169
5.3 851 21.8 1327 129 1327 1.0 339.627 27.578 g500-H1500 MFXMA 132-22 2 128
4.9 920 20.1 1435 119 1435 1.8 343.304 29.822 g500-H3000 MFXMA 132-22 2 169
4.0 1117 16.6 1742 98.4 1742 1.5 341.377 36.193 g500-H3000 MFXMA 132-22 2 169
3.1 1434 12.7 2237 75.4 2237 1.1 351.742 47.186 g500-H3000 MFXMA 132-22 3 174
2.7 1634 11.2 2549 66.2 2549 1.0 348.174 53.770 g500-H3000 MFXMA 132-22 3 174
2.2 1968 9.3 3069 55.0 3069 0.8 345.627 64.744 g500-H3000 MFXMA 132-22 3 174
Technical data
Selecon tables
79
