Lenze SMV Series User Manual

15
EDBSV571 EN 1.0
EN
Installation
3.2.2 Fuses/Cable Cross-Sections
NOTE: Observe local regulations. Local codes may supersede these recommendations
WARNING: Per UL, use a FUSE for 240V drives requiring >40A protection and for 400/480/600V drives requiring >32A protection.
Type
Recommendations
Fuse
Miniature
circuit
breaker
(1)
Fuse
(2)
Breaker
(3)
Input Power Wiring
(L1, L2, L3, PE)
North America [mm²] [AWG]
120V
1~
(1/N/PE)
ESV251N01SXB M10 A C10 A 10 A 10 A 1.5 14
ESV371N01SXB M16 A C16 A 15 A 15 A 2.5 14
ESV751N01SXB M25 A C25 A 25 A 25 A 4 10
ESV112N01SXB M32 A C32 A 30A 30A 4 10
240V
1~
(2/PE)
ESV251N01SXB, ESV251N02SXB,
ESV371N01SXB, ESV371N02YXB
M10 A C10 A 10 A 10 A 1.5 14
ESV751N01SXB, ESV751N02YXB M16 A C16 A 15 A 15 A 2.5 14
ESV112N02YXB, ESV112N01SXB M20 A C20 A 20 A 20 A 2.5 12
ESV152N02YXB M25 A C25 A 25 A 25 A 2.5 12
ESV222N02YXB M32 A C32A 30 A 30 A 4 10
240V
3~
(3/PE)
ESV371N02YXB, ESV751N02YXB M10 A C10 A 10 A 10 A 1.5 14
ESV112N02YXB, ESV152N02YXB,
ESV112N02TXB, ESV152N02TXB
M16 A C16 A 12 A 12 A 1.5 14
ESV222N02YXB, ESV222N02TXB M20 A C20 A 20 A 20 A 2.5 12
ESV402N02TXB M32 A C32 A 30 A 30 A 4.0 10
ESV552N02TXB M40 A C40 A 35 A 35 A 6.0 8
ESV752N02TXB M50 A C50 A 45 A 10 8
ESV113N02TXB M80 A C80 A 80 A 16 6
ESV153N02TXB M100 A C100 A 90 A 16 4
400V
or 480V
3~(3/PE)
ESV371N04TXB ...ESV222N04TXB M10 A C10 A 10 A 10 A 1.5 14
ESV402N04TXB M16 A C16 A 20 A 20 A 2.5 14
ESV552N04TXB M20 A C20 A 20 A 20 A 2.5 14
ESV752N04TXB M25 A C25 A 25 A 25 A 4.0 10
ESV113N04TXB M40 A C40 A 40 A 4 8
ESV153N04TXB M50 A C50 A 50 A 10 8
ESV183N04TXB M63 A C63A 70 A 10 6
ESV223N04TXB M80 A C80 A 80 A 16 6
600V
3~(3/PE)
ESV751N06TXB ...ESV222N06TXB M10 A C10 A 10 A 10 A 1.5 14
ESV402N06TXB M16 A C16 A 12 A 12 A 1.5 14
ESV552N06TXB M16 A C16 A 15 A 15 A 2.5 14
ESV752N06TXB M20 A C20 A 20 A 20 A 2.5 12
ESV113N06TXB M32 A C32 A 30 A 30 A 4 10
ESV153N06TXB M40 A C40 A 40 A 4 8
ESV183N06TXB M50 A C50 A 50 A 6 8
ESV223N06TXB M63 A C63 A 60 A 10 8
Notes for Fuse and Cable Table:
(1) Installations with high fault current due to large supply mains may require a type D circuit breaker.
(2) UL Class CC or T fast-acting current-limiting type fuses, 200,000 AIC, preferred. Bussman KTK-R, JJN or JJS or equivalent.
(3) Thermomagnetic type breakers preferred.
Observe the following when using Ground Fault Circuit Interrupters (GFCIs):
• InstallationofGFCIonlybetweensupplyingmainsandcontroller.
• TheGFCIcanbeactivatedby:
- capacitive leakage currents between the cable screens during operation (especially with long, screened motor cables)
- connecting several controllers to the mains at the same time
- RFI filters
