4-9
Owner's Manual Addendum
Controlling the LXP-5 with Two-Way Communication
flicker when sliders are moved on the MRC.) Refer to the
MRC V3.0 Owner’s
Manual
for a complete description of how to use the MRC to edit LXP-5 setup
parameters.
Using the
✱
and ENTER Keys
While in Machine Run Mode, the ✱ key transmits the current values of all
parameters to the LXP-5. Use it to reset the LXP-5 to the values displayed
by the MRC. (You would do this, for example, if LXP-5 parameters are
inadvertently changed from its front panel.) If you are using two-way
communication, you can press ENTER to update the MRC to the current
parameter values of the LXP-5. This allows you to transfer new settings to
the MRC after front panel adjustment of the LXP-5.
Storing Setups from Machine Run Mode
You can store a setup you’ve created in any one of the MRC’s sixteen
internal setups, or in any one of the LXP-5’s 128 user registers. Here’s how:
1. On the MRC, press STORE to enter Setup Store Mode.
2. Move slider 2 to select “MRC SETUP” or “LXP-5 RGSTR”
3. Use slider 1, the SETUP key or the keypad to select a setup number.
Valid numbers for MRC setups are 1–16. For LXP-5 registers, valid
numbers are 1–128. The display will blink if you enter an invalid number.
(Simply enter a valid setup number if this occurs.)
4. Press ENTER to store the setup and return to Machine Run Mode
OR
Press MACH to exit Setup Store Mode and return to Machine Run Mode
without
storing the setup.
