Lexmark XC4143 User Manual

4 Type a unique profile name.
Note: We recommend creating a PIN to protect the
profile.
5 Tou ch OK, and then take note of the authorization code.
Note: The authorization code is valid only for 24 hours.
6 Open a web browser, and then go to https://lexmark.cloud-connect.co.
7 Click Next, and then accept the Terms of Use.
8 Enter the authorization code, and then click Connect.
9 Log in to your cloud service provider account.
10 Grant permissions.
Note: To complete the authorization process, open the profile within 72 hours.
Managing bookmarks
Creating bookmarks
Use bookmarks to print frequently accessed documents that are stored in servers or on the web.
1 Open a web browser, and then type the printer IP address in the address field.
Notes:
• View the printer IP address on the printer home screen. The IP address appears as four sets of
numbers separated by periods, such as 123.123.123.123.
• If you are using a proxy server, then temporarily disable it to load the web page correctly.
2 Click Bookmarks > Add Bookmark, and then type a bookmark name.
3 Select an Address protocol type, and then do one of the following:
• For HTTP and HTTPS, type the URL that you want to bookmark.
• For HTTPS, make sure to use the host name instead of the IP address. For example, type
myWebsite.com/sample.pdf instead of typing 123.123.123.123/sample.pdf. Make sure that
the host name also matches the Common Name (CN) value in the server certificate. For more information
on obtaining the CN value in the server certificate, see the help information for your web browser.
• For FTP, type the FTP address. For example, myServer/myDirectory. Enter the FTP port. Port 21 is
the default port for sending commands.
• For SMB, type the network folder address. For example, myServer/myShare/myFile.pdf. Type the
network domain name.
• If necessary, select the Authentication type for FTP and SMB.
To limit access to the bookmark, enter a PIN.
Note: The application supports the following file types: PDF, JPEG, TIFF, and HTML-based web pages.
Other file types such as DOCX and XLXS are supported in some printer models.
4 Click Save.
Setting up and using the home screen applications 22

Lexmark XC4143 Specifications

General

Print Technology	Color Laser
Print Speed (Black)	43 ppm
Print Speed (Color)	43 ppm
Print Resolution	1200 x 1200 dpi
Scan Technology	CIS
ADF Capacity	100 sheets
Standard Input Capacity	650 sheets
Maximum Paper Input Capacity	2300 sheets
Standard Output Capacity	300 sheets
Duplex Printing	Yes
Display	7-inch color touch screen
Standard Memory	2048 MB
Maximum Memory	4096 MB
Processor Speed	1.2 GHz
Scan Resolution	600 x 600 dpi
Functions	Print, Copy, Scan, Fax
Connectivity	USB, Ethernet
Maximum Monthly Duty Cycle	100, 000 pages
Max Paper Size	A4
