5.3. 3D mode
5.3.1. RF Input
No Resolution Proposed 3D input proposed mode
1 HD 1080I
720P
2D to 3D
Side by Side(Half)
Top & Bottom
2 SD 576P
576I
2D to 3D
5.3.2. RF Input (3D supported mode automatically)
5.3.3. HDMI Input 1.3(3D supported mode manually)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
1 1280*720 45.00 60.00 74.25 HDTV 720P 2D to 3D
Side by Side(half),
Top & Bottom,
Single Frame Sequential
2 1280*720 37.500 50 74.25 HDTV 720P 2D to 3D
Side by Side(half),
Top & Bottom,
Single Frame Sequential
3 1920*1080 33.75 60.00 74.25 HDTV 1080I 2D to 3D
Side by Side(half),
Top & Bottom
4 1920*1080 28.125 50.00 74.25 HDTV 1080I 2D to 3D
Side by Side(half),
Top & Bottom
5 1920*1080 27.00 24.00 74.25 HDTV 1080P 2D to 3D
Side by Side(half),
Top & Bottom,
Checkerboard
6 1920*1080 28.12 25 74.25 HDTV 1080P 2D to 3D
Side by Side(half),
Top & Bottom,
Checkerboard
7 1920*1080 33.75 30.00 74.25 HDTV 1080P 2D to 3D
Side by Side(half),
Top & Bottom,
Checkerboard
8 1920*1080 56.25 50 148.5 HDTV 1080P 2D to 3D
Side by Side(half),
Top & Bottom,
Checkerboard,
Single Frame Sequential,
Row Interleaving,
Column Interleaving
9 1920*1080 67.50 60.00 148.5 HDTV 1080P 2D to 3D
Side by Side(half),
Top & Bottom,
Checkerboard,
Single Frame Sequential,
Row Interleaving,
Column Interleaving
No Signal 3D input proposed mode
1 Frame Compatible Side by Side(Half), Top & Bottom

LG 42LN5700 Specifications

General

Display diagonal	42 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	-
Supported video modes	1080i, 1080p, 720p
Screen format adjustments	4:3
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	TruMotion 120 Hz
3D	No
Photo effects	Cinema, Vivid
Playback modes	Zoom
Volume control	Digital
Audio decoders	Dolby Digital, Dolby Digital DTS
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	SimpLink
Smart modes	Cinema, Game
Lifestyle apps	Skype
Audio formats supported	AAC, AC3, MP3, PCM
Video formats supported	DIVX, DIVX HD, MPEG
Control type	Buttons
Product color	Black
Panel mounting interface	200 x 200 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	41.4 W
Sustainability certificates	ENERGY STAR
Package depth	175 mm
Package width	1150 mm
Package height	659.8 mm
Package weight	14197 g

Weight and Dimensions

Depth (with stand)	234.9 mm
Height (with stand)	627.8 mm
Weight (with stand)	10704 g
Depth (without stand)	78.9 mm
Width (without stand)	967.9 mm
Height (without stand)	565.9 mm
Weight (without stand)	9616 g
