LG 42LN5700 Service Manual

32 / 97
Status Power off List Explanation
Normal
POWER_OFF_BY_REMOTE KEY POWER_OFF_BY_REMOTE CONTROL
POWER_OFF_BY_OFF_TIMER POWER_OFF_BY_OFF TIMER
POWER_OFF_BY_SLEEP_TIMER POWER_OFF_BY_SLEEP TIMER
POWER_OFF_BY_TS_END POWER_OFF_BY_REMOTE or LOCAL KEY While recording
POWER_OFF_BY_INSTOP_KEY POWER_OFF_BY_INSTOP KEY
POWER_OFF_BY_AUTO_OFF POWER_OFF_BY_AUTO OFF
POWER_OFF_BY_ON_TIMER POWER_OFF_BY_ON TIMER
POWER_OFF_BY_RS232C POWER_OFF_BY_RS232C
POWER_OFF_BY_RESREC POWER_OFF_BY_Reservated Record
POWER_OFF_BY_RECEND POWER_OFF_BY_End of Recording
POWER_OFF_BY_SWDOWN POWER_OFF_BY_S/W Download
POWER_OFF_BY_LOCAL_KEY POWER_OFF_BY_LOCAL KEY
POWER_OFF_BY_OTA POWER_OFF_BY_End of OTA
POWER_OFF_BY_SIGNAL_DETECT POWER_OFF_BY_Another MICOM (Only OLED)
POWER_OFF_BY_RESET POWER_OFF_BY_Factory Reset
POWER_OFF_BY_UNKNOWN POWER_OFF_BY_unknown status except listed case
Abnormal
POWER_OFF_BY_ABN POWER_OFF_BY_abnormal Panel status
POWER_OFF_BY_KEY_TIMEOUT POWER_OFF_BY_abnormal Power Off Key At Warm/Hot status
POWER_OFF_BY_ACDET POWER_OFF_BY_AC OFF
POWER_OFF_BY_5VMNT POWER_OFF_BY_AC DETECT
POWER_OFF_BY_NO_POLLING POWER_OFF_BY_MCU Abnormal for 15 sec.
POWER_OFF_BY_1SEC_POWER_OFF POWER_OFF_BY_MCU Abnormal status with Power Off Key
POWER_OFF_BY_20VMNT POWER_OFF_BY_abnormal Panel status (Only OLED)
Appendix : Power OFF History
Copyright ⓒ 2013 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only

LG 42LN5700 Specifications

General

Display diagonal	42 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	-
Supported video modes	1080i, 1080p, 720p
Screen format adjustments	4:3
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	TruMotion 120 Hz
3D	No
Photo effects	Cinema, Vivid
Playback modes	Zoom
Volume control	Digital
Audio decoders	Dolby Digital, Dolby Digital DTS
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	SimpLink
Smart modes	Cinema, Game
Lifestyle apps	Skype
Audio formats supported	AAC, AC3, MP3, PCM
Video formats supported	DIVX, DIVX HD, MPEG
Control type	Buttons
Product color	Black
Panel mounting interface	200 x 200 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	41.4 W
Sustainability certificates	ENERGY STAR
Package depth	175 mm
Package width	1150 mm
Package height	659.8 mm
Package weight	14197 g

Weight and Dimensions

Depth (with stand)	234.9 mm
Height (with stand)	627.8 mm
Weight (with stand)	10704 g
Depth (without stand)	78.9 mm
Width (without stand)	967.9 mm
Height (without stand)	565.9 mm
Weight (without stand)	9616 g
