LG 42LN5700 Service Manual

- 13 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
5.3.4. HDMI Input 1.4b (3D supported mode automatically)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) 3D input proposed
mode
Proposed
1 640*480 31.469 / 31.5 59.94/ 60 25.175/25.2 Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 480P)
Secondary(SDTV 480P)
2 62.938 / 63 59.94/ 60 50.35/50.4 Frame packing
Line alternative
Secondary(SDTV 480P)
(SDTV 480P)
3 31.469 / 31.5 59.94/ 60 50.35/50.4 Side-by-side(Full) (SDTV 480P)
4 720*480 31.25 50 27 Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 480P)
Secondary(SDTV 480P)
5 62.5 50 54 Frame packing
Line alternative
Secondary(SDTV 480P)
(SDTV 480P)
6 31.25 50 54 Side-by-side(Full) (SDTV 480P)
7 720*576
(576p)
720 (1440)*576
(576i)
31.25 50 27 Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 576P)
Secondary(SDTV 576P)
8 62.5 50 54 Frame packing
Line alternative
Secondary(SDTV 576P)
(SDTV 576P)
9 31.25 50 54 Side-by-side(Full) (SDTV 576P)
10 15.625 50 27 Top-and-Bottom
Side-by-side(half)
Secondary(SDTV 576I)
Secondary(SDTV 576I)
11 31.25 50 54 Frame packing
Field alternative
Secondary(SDTV 576I)
(SDTV 576I)
12 15.625 50 54 Side-by-side(Full) (SDTV 576I)
13 1280*720 37.5 50 74.25 Top-and-Bottom
Side-by-side(half)
Primary(HDTV 720P)
Primary(HDTV 720P)
14 75 50 148.5 Frame packing
Line alternative
Primary(HDTV 720P)
(HDTV 720P)
15 37.5 50 148.5 Side-by-side(Full) (HDTV 720P)
16 44.96 / 45 59.94 / 60 74.18/74.25 Top-and-Bottom
Side-by-side(half)
Primary(HDTV 720P)
Primary(HDTV 720P)
17 89.91 / 90 59.94 / 60 148.35/148.5 Frame packing
Line alternative
Primary(HDTV 720P)
(HDTV 720P)
18 44.96 / 45 59.94 / 60 148.35/148.5 Side-by-side(Full) (HDTV 720P)

LG 42LN5700 Specifications

General

Display diagonal	42 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	-
Supported video modes	1080i, 1080p, 720p
Screen format adjustments	4:3
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	TruMotion 120 Hz
3D	No
Photo effects	Cinema, Vivid
Playback modes	Zoom
Volume control	Digital
Audio decoders	Dolby Digital, Dolby Digital DTS
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	SimpLink
Smart modes	Cinema, Game
Lifestyle apps	Skype
Audio formats supported	AAC, AC3, MP3, PCM
Video formats supported	DIVX, DIVX HD, MPEG
Control type	Buttons
Product color	Black
Panel mounting interface	200 x 200 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	41.4 W
Sustainability certificates	ENERGY STAR
Package depth	175 mm
Package width	1150 mm
Package height	659.8 mm
Package weight	14197 g

Weight and Dimensions

Depth (with stand)	234.9 mm
Height (with stand)	627.8 mm
Weight (with stand)	10704 g
Depth (without stand)	78.9 mm
Width (without stand)	967.9 mm
Height (without stand)	565.9 mm
Weight (without stand)	9616 g
