LG 42LN5700 Service Manual

- 7 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
4. General Specification
No Item Specication Remark
1. Display Screen Device 32” wide Color Display Module Resolution: 1366*768 (32LN570)
32” wide Color Display Module Resolution: 1920*1080
39” wide Color Display Module Resolution: 1920*1080
42” wide Color Display Module Resolution: 1920*1080
47” wide Color Display Module Resolution: 1920*1080
50” wide Color Display Module Resolution: 1920*1080
55” wide Color Display Module Resolution: 1920*1080
60” wide Color Display Module Resolution: 1920*1080
2. Aspect Ratio 16:9 All
3. LCD Module 32" TFT WUXGA LCD
32" TFT WXGA LCD Only 32LN570B
42" TFT WUXGA LCD
47” TFT WUXGA LCD
50” TFT WUXGA LCD
55” TFT WUXGA LCD
60” TFT WUXGA LCD
4. Operating Environment TFT 1) Temp. : 0 ~ 40 deg
2) Humidity : 0 ~ 85%
LGE SPEC
5. Storage Environment TFT 1) Temp. : -20 ~ 60 deg
2) Humidity : 10 ~ 90%
6. Input Voltage AC100 ~ 240V, 50/60Hz
7. Power Consumption(Max) =
LCD(Module) + Backlight(LED)
FHD
T240Hz
POLA
60 TBD W FPR : LC600DUK-SEF1 [60LA7450/LA6200-DA]
FHD
T120Hz
POLA
55 TBD W FPR : LC550EUJ-SEK1 [55LA6200-DA]
FHD
60Hz POLA
55 TBD W Normal : LC550EUJ-SEE1 [55LN5700-DC]
FHD
T120Hz
CINEMA
42” 56.4 W FPR: LC420EUG-KFF1 [42LA65/66/68/6900-DA]
47” 62.4 W FPR: LC470EUG-KFF1 [47LA66/68 6900-DA]
55” 74.3 W FPR: LC550EUG-KFF1 [55LA66/68/6900-DA]
FHD
T120Hz
Edge
42” 57 W FPR: LC420EUN-SFF2 [42LA6400-DA]
47” 68 W FPR: LC470EUN-SFF2 [47LA6400-DA]
50” 76 W FPR: LC500EUN-SFF1 [50LA6400-DA]
55” 88 W FPR: LC550EUN-SFF1 [55LA6400-DA]
FHD
T120Hz
Direct
42” 77 W FPR : LC420DUE-SFU1 [42LA6200-DA]
77 W Normal : LC420DUE-SFR1 [42LN5700-DH]
47” 91 W FPR : LC470DUE-SFU1 [47LA6200-DA]
91 W Normal : LC470DUE-SFR1 [47LN5700-DH]
50” 108 W FPR : LC500DUE-SFU1 [50LA6200-DA]
HD (32”
only)
FHD
60Hz
Direct
(32/42/47”)
POLA (55”)
42” 62.34 W Normal : LC420DUE-SFR1 [42LN5700-DH]
47” 91 W Normal : LC470DUE-SFR1 [47LN5700-DH]
55” Normal : LC550DUK-SEE1 [55LN5700-DC]
32” 39.2 W LC320DXE-SFR1 [32LN570B (HD)]
38 W LC320DUE-SFR1 [32LN5700(FHD)]

LG 42LN5700 Specifications

General

Display diagonal	42 \
Native aspect ratio	16:9
Native refresh rate	60 Hz
LED backlighting type	-
Supported video modes	1080i, 1080p, 720p
Screen format adjustments	4:3
Supported graphics resolutions	1920 x 1080 (HD 1080)
Motion interpolation technology	TruMotion 120 Hz
3D	No
Photo effects	Cinema, Vivid
Playback modes	Zoom
Volume control	Digital
Audio decoders	Dolby Digital, Dolby Digital DTS
RMS rated power	20 W
Number of speakers	2
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	SimpLink
Smart modes	Cinema, Game
Lifestyle apps	Skype
Audio formats supported	AAC, AC3, MP3, PCM
Video formats supported	DIVX, DIVX HD, MPEG
Control type	Buttons
Product color	Black
Panel mounting interface	200 x 200 mm
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	41.4 W
Sustainability certificates	ENERGY STAR
Package depth	175 mm
Package width	1150 mm
Package height	659.8 mm
Package weight	14197 g

Weight and Dimensions

Depth (with stand)	234.9 mm
Height (with stand)	627.8 mm
Weight (with stand)	10704 g
Depth (without stand)	78.9 mm
Width (without stand)	967.9 mm
Height (without stand)	565.9 mm
Weight (without stand)	9616 g
