Checking order when there is no audio
Check the contact condition of cable or connector
Measure the 13.2V input voltage supplied from Power Board
(If there is no input voltage, remove and check the connector)
Check the sound
Standard Repair Process Detail Technical Manual
Voltage and speaker checking method
when there is no audio
C. Audio error_No audio/Normal video
A21
Established
date
Revised
date
Error
symptom
Content
A21
<UH63/65/75>
1
SPK_R-
2
SPK_R+
3
SPK_L
4
SPK_L+
Main B/D Side
Pin map
reversed
1
GND
2
GND
3
PWR-On
4
P-DIM2
5
GND
6
13.2V
7
13.2V
8
13.2V
9
13.2V
10
13.2V
11
GND
12
GND
13
P-DIM1
14
DRV-On
15
SCLK
16
GND
17
SIN
18
VSINC
18Pin map (LPB)
1
PWR-On
2
P-DIM2
3
GND
4
13.2V
5
13.2V
6
13.2V
7
13.2V
8
13.2V
9
GND
10
GND
11
MS
12
P-DIM1
12Pin map (LPB)
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only
