THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
15/06/13
73RS232C
C7204
0.1uF
RS232C
+3.5V_ST
C7203
0.1uF
RS232C
C7202
0.1uF
RS232C
IC7200
MAX3232CDR
EAN41348201
RS232C
3
C1-
2
V+
4
C2+
1
C1+
6
V-
5
C2-
7
DOUT2
8
RIN2
9
ROUT2
10
DIN2
11
DIN1
12
ROUT1
13
RIN1
14
DOUT1
15
GND
16
VCC
R7201
100
RS232C
C7200
0.1uF
RS232C
VA7200
20V
OPT
HP_ROUT_JACK
VA7201
20V
OPT
SOC_RX
C7201
0.1uF
RS232C
R7200
100
RS232C
SOC_TX
HP_LOUT_JACK
RIN1
DOUT1
RS-232C Control INTERFACE
RS232C TO PHONE JACK
(US ONLY)
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only
