LG 49UH6500 - Headphone Jack Circuitry; Headphone Jack Connections

THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
15/06/13
HP JACK 73
HP_ROUT_JACK
HP_DET
VA6200
5.6V
HP_OUT
HP_LOUT_JACK
R6200
10K
HP_OUT
+3.3V_NORMAL
JK6200
PEJ034-01
EAG60841811
6B
T_TERMINAL2
7B
B_TERMINAL2
5
T_SPRING
4
R_SPRING
3
E_SPRING
23
HP OUT
