THERMAL
THE SYMBOL MARK OF THIS SCHEMETIC DIAGRAM INCORPORATES
SPECIAL FEATURES IMPORTANT FOR PROTECTION FROM X-RADIATION.
FIRE AND ELECTRICAL SHOCK HAZARDS, WHEN SERVICING IF IS
ESSENTIAL THAT ONLY MANUFACTURES SPECIFIED PARTS BE USED FOR
THE CRITICAL COMPONENTS IN THE SYMBOL MARK OF THE SCHEMETIC.
I2C_SCL0
C5306
22000pF
50V
L5302
NRS6045T100MMGK
10.0uH
10uF
C5309
35V
C5303
1uF
10V
L5300
BLM18PG121SN1D
0.1uF
C5320
50V
C5314
22000pF
50V
0.1uF
C5302
16V
POWER_DET
+13V_AMP_FRONT
R5308
4.7K
R5311
4.7K
+3.3V_NORMAL
C5300
33pF
50V
C5315
22000pF
50V
L5304
NRS6045T100MMGK
10.0uH
C5317
390pF
50V
C5319
0.47uF
50V
R5306
3.3
1/10W
AMP_MUTE
R5301
10K
AUD_LRCH
0.1uF
C5321
50V
C5312
390pF
50V
SPK_L-_FT
C5310
1uF 10V
IC5300
NTP7515
EAN62886102
3
NC_2
2
VDD_PLL
4
GND
1
NC_1
6
DVDD
5
NC_3
7
SDATA
8
WCK
9
NC_4
10
SDA
11
SCL
12
FAULT
13
MONITOR_0
14
MONITOR_1
15
MONITOR_2
16
BST2B
17
PGND2B
18
OUT2B
19
PVDD2B
20
PVDD2A
21
OUT2A
22
PGND2A
23
BST2A
24
VDR2
25
AGND
26
NC_5
27
VDR1
28
BST1B
29
PGND1B
30
OUT1B
31
PVDD1B
32
PVDD1A
33
OUT1A
34
PGND1A
35
BST1A
36
RESET
37
AD
38
CLK_I
39
GND_IO
40
VDD_IO
41
[EP]GND
C5318
0.47uF
50V
R5304
3.3
1/10W
0.1uF
C5322
50V
L5303
NRS6045T100MMGK
10.0uH
AUD_LRCK
I2S_AMP
R5307
3.3
1/10W
SPK_L+_FT
R5300
10K
WOOFER_MUTE
AR5300
100
1/16W
0.1uF
C5323
50V
C5313
390pF
50V
10uF
C5308
35V
C5304
1uF
10V
R5302
100
OPT
R5309
4.7K
AMP_RESET_N
R5303
100
+3.3V_NORMAL
SPK_R+_FT
Q5300
MMBT3904(NXP)
E
B
C
R5305
3.3
1/10W
I2C_SDA0
C5301
33pF
50V
+13V_AMP_FRONT
WOOFER_MUTE
L5301
NRS6045T100MMGK
10.0uH
C5311
1uF 10V
AUD_SCK
C5316
390pF
50V
C5307
22000pF
50V
SPK_R-_FT
R5310
4.7K
C5305
1000pF
50V
A13V
L5305
UBW2012-121F
+13V_AMP_FRONT
NTP AMP
2015.02.24
20
M16
26
053.sht
SPEAKER_R
NTP_AMP_Front
SPEAKER_L
0x54
Copyright © 2016 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG 49UH6500 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	49 \
Display brightness	- cd/m²
Native refresh rate	60 Hz
Supported video modes	2160p
Screen format adjustments	16:9
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	TruMotion 120 Hz
3D	No
Annual energy consumption	104 kWh
Package depth	174 mm
Package width	1197 mm
Package height	810 mm
Package weight	17700 g
Product color	Silver
Panel mounting interface	300 x 300 mm
Audio decoders	DTS, Dolby Digital
RMS rated power	20 W
Number of speakers	2
Sustainability certificates	ENERGY STAR
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Cables included	AC
Operating system version	3.0
Operating system installed	Web OS
Wi-Fi standards	Wi-Fi 5 (802.11ac)
HDMI ports quantity	3
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Consumer Electronics Control (CEC)	SimpLink
Number of OSD languages	4
Teletext function	-
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (with stand)	282 mm
Height (with stand)	702 mm
Weight (with stand)	13700 g
Depth (without stand)	77.2 mm
Width (without stand)	1106 mm
Height (without stand)	646 mm
Weight (without stand)	9700 g
