NOTE
► When assembling the desk type stand,
make sure the screws are fully tightened (If
not tightened fully, the TV can tilt forward
after the product installation). Do not over
tighten.
1
Carefully place the TV screen side down on
a cushioned surface to protect the screen
from damage.
2
Assemble the parts of the STAND BODY
with the STAND BASE of the TV.
3
Assemble the parts of the CABLE
MANAGEMENT CLIP with the STAND
BODY.
5
Install the 4 screws into the holes shown.
M4 x 28
4
Assemble the TV as shown.
STAND BASE
STAND BODY
STAND BODY
CABLE
MANAGEMENT
CLIP
M4 x 14
To Next Page
