29
ENGLISH_index
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
OLED screen Screen type Thin Film Transistor (TFT)
OLED Screen
Operating conditions Daily usage 18hours (video)
Video signal Maximum resolution 3840 x 2160 @ 30Hz
- This may not be supported on some OS or graphics
card types.
Recommended resolution 1920 x 1080 @ 60Hz
- This may not be supported on some OS or graphics
card types.
Horizontal frequency 30kHz to 83kHz
Vertical frequency 56Hz to 60Hz
Synchronization Separate Sync, Digital
Input/ Output ports
Embedded battery Applied
Environmental Conditions Operating Temperature 0°C to 40°C (32 °F to 104 °F)
Operating Humidity 10% to 80%
Storage Temperature -20°C to 60°C (-4 °F to 140 °F)
Storage Humidity 5% to 85%
OLED Panel Pixel Pitch 0.630mm (H) X 0.630mm (V)
Power Rated Voltage 100-240V~ 50/60Hz 3.7A
Power Consumption On Mode: 280W (Typ.)
Sleep Mode: ≤ 0.5W
Standby Mode: ≤ 0.5W
Dimensions (Width x Height
x Depth) / Weight
Display 1225.5mm x 832.9mm x 7.4mm / 12.9kg
(48.2 inches x 32.7 inches x 0.2 inches / 28.4 lbs)
Signage Box 782.8mm x 239mm x 34.6mm / 3.4kg
(30.8 inches x 9.4 inches x 1.3 inches / 7.4 lbs)
