CIRCUIT VOLTAGE CHART
1. CAPACITOR VOLTAGE
3-71 3-72
Location Value Capacitor (uF) Voltage_Spec (V)
100 V - 10 % 240 V/ 50 Hz +10 %
Measured voltage (V) Measured voltage (V)
SMPS Board
C904 330 450 393 393
C926 47 50 15.7 16
C927 47 50 17 17.5
C930 68 450 138 336
C936 1000 16 5.65 5.65
C937 2200 16 5.67 5.67
C939 10 50 3.2 3.2
C944 1000 25 12.7 12.73
C948 220 25 7.24 7.24
C957 220 25 12.68 12.7
C963 3300 25 16.35 16.35
C964 220 25 12.05 12.05
C966 1000 80 66.46 66.45
C968 1000 80 65.9 65.9
MAIN/ FRONT Board
C231 100 16 4.89 4.89
C238 220 6.3 3.26 3.26
C240 220 6.3 1.24 1.24
C308 47 16 5.14 5.14
C347 470 10 3.37 3.37
C402 100 16 4.90 4.90
C404 47 16 3.28 3.28
C409 47 16 3.28 3.28
C416 47 16 1.63 1.63
C418 3.3 50 0.49 0.49
C427 220 16 4.91 4.91
C501 220 6.3 2.93 2.93
C5C9 1000 6.3 3.25 3.25
C707 2200 80 65.8 65.8
C728 2200 80 65.8 65.8
C752 1000 80 65.8 65.8
C752-*1 2200 80 65.8 65.8
C798 1000 80 65.8 65.8
C798-*1 2200 80 65.8 65.8

LG CM8460 Specifications

General

Type	Home audio mini system
Cassette deck	-
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
RMS rated power	2750 W
Number of speakers	2
Number of subwoofers	1
Subwoofer driver diameter (imperial)	10 \
Power source	AC
Power consumption (standby)	0.5 W
Power consumption (typical)	250 W
Supported radio bands	FM
Audio formats supported	MP3, WMA
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported

Weight and Dimensions

Weight	34900 g
Package depth	520 mm
Package width	1266 mm
Package height	453 mm
Package weight	37700 g
Main unit weight	6000 g
Subwoofer weight	9500 g
Main unit dimensions (WxDxH)	450 x 355 x 160 mm
Subwoofer dimensions (WxDxH)	325 x 302 x 454 mm
