LG CM8460 User Manual

4-3
DECK MECHANISM DISASSEMBLY
3) Grasp the both sides of the Tray Disc and lift
it up as Figure D, and then pull the Tray Disc
until it is separated from the MD Sub Assembly
completely.
Note
• When reassembling place the Guide as Figure E.
MD Sub
Assembly
< Figure D >
3
1 1
22
Tray Disc
Tray Disc
< Figure E >
Guide
3. Tray Disc
1) Insert and push a flat-head screwdriver in the
Emergency eject hole (H1) at the right side, so
that the Tray Disc is ejected about 15 ~ 20 mm.
2) Pull the Tray Disc until it is locked.
< Bottom side view >
Tray Disc
Tray Disc
< Figure C >
2
1
(H1)
Emergency eject hole

LG CM8460 Specifications

General

Type	Home audio mini system
Cassette deck	-
Product color	Black
Optical disc player	Yes
Number of optical discs	1 discs
RMS rated power	2750 W
Number of speakers	2
Number of subwoofers	1
Subwoofer driver diameter (imperial)	10 \
Power source	AC
Power consumption (standby)	0.5 W
Power consumption (typical)	250 W
Supported radio bands	FM
Audio formats supported	MP3, WMA
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Apple docking compatibility	Not supported

Weight and Dimensions

Weight	34900 g
Package depth	520 mm
Package width	1266 mm
Package height	453 mm
Package weight	37700 g
Main unit weight	6000 g
Subwoofer weight	9500 g
Main unit dimensions (WxDxH)	450 x 355 x 160 mm
Subwoofer dimensions (WxDxH)	325 x 302 x 454 mm
