LG LP1415GXR Service Manual

- 46 -
Copyright ©2014 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Wring diagram
Test point
Result
3214
Test points Result Remark
˄
1˅to˄2˅ 5 KΩ˄25ć˅ When it’s defect, display CH02
˄
3˅to˄4˅ 5 KΩ˄25ć˅ When it's defect, display CH01
DC5V
CONNECTOR
MA IN
CHIP
C=2.2uf
C=2.2uf
R=4.99K
R=4.99K
PUMP SENSOR
AMBIENT SENSOR
O
O
O
O
10-5 Temp sensor
10. COMPONENT TESTING IMFORMATION
