- 6 -

Only for training and service purposes

LGE Internal Use Only

4-1 PREPARING FOR INSTALLATION

2 Type A Screws 1 Type B Screw 1 Type C Screw

The following components are used for window venting.

Not all components are used for every installation.

EXHAUST COMPONENTS

Window Installation Kit (includes 1 Window

Vent Panel and 3 Extension Panels)

Flexible Venting Hose

2 Type A Foam Seals

(Adhesive)

Diffuser

Security Bracket

1 Type B Foam Seal

(Non-adhesive)

2 Type C Foam Seals

(Adhesive type-Shorter)

?):616/ <PMIQZKWVLQ\QWVMZQ[PMI^a=[M\_WWZUWZMXMWXTM\W

TQN\IVLQV[\ITT\PM]VQ\.IQT]ZM\WLW[WKW]TLZM[]T\QVJIKSQVR]ZaWZW\PMZQVR]ZQM[

1 Window Vent Panel

Panel A (18’’)

3 Extension Panels

Panel C (17’’)

Panel D (17’’)

Panel B (9’’)

Fixing Nut

Additional Parts (For Heating Drainage)

Drain Pipe

(In The Accessory Box)

(On the Vent Panel)

Nut Cover

4. INSTALLATION
