NOTE: The window installation kit can be used with vertical sliding windows between
18" and 50" wide.
Foam seal A
(Adhesive type)
Foam seal C
(Adhesive type-shorter)
1
Cut the foam seal A (adhesive type) &
C (adhesive type-shorter) to the proper
length, and attach it to the window sash
and frame.
2
Insert the vent panel assembly, including
extension panels, if needed, into the window
opening. Extend the extension panels, if
used.
Foam seal B
(Non-adhesive type)
3
Cut the foam seal B (Non-adhesive type) to
the window width. Stuff the foam seal B
between the glass and the window to
prevent air and insects from getting into the
room.
4
Install the security bracket with a type B
screw as shown if you need.
Type B
screw
Security Bracket
Extension panel
(if required)
Vent
Panel
4-4 INSTALLATION IN VERTICAL SLIDING WINDOWS
To Next Page
