3-26
Copyright © 2018 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
ELECTRICAL TROUBLESHOOTING GUIDE
2. MCS PART CHECK
YES
YES
YES
YES
YES
MCS PART CHECK
OK
Refer to SMPS troubleshooting.
Check and change IC204.
X501: 32.768 kHz, X500: 24 MHz
Check the operation.
Check and change IC202, IC205.
NO
NO
NO
Check if voltage
of CN201 pin1, 2: 12 V.
Check if IC204
have DVCC_3.3V output.
Check if IC202, IC205
have 3.3 VA & 1.2 VA output.
