3-29

Only for training and service purposes.

ELECTRICAL TROUBLESHOOTING GUIDE

5. POWER AMP PART CHECK

YES

POWER AMP PART CHECK

Refer to SMPS troubleshooting.

Check each line resistor output voltage.

Replace the coil.

Check IC701, IC702

Pin51, 52, 42, 43, 38, 39, 30, 31 input voltage.

Check PWM modulator input

IC701 pin4, 5/ IC702 pin4, 5, 10, 11.

Check IC701, IC702

pin28, 29, 36, 37, 44, 45, 52, 53.

Check CN201 pin1, 2: 12 V,

pin8, 9, 10: 48.5 V (35.5 V).

Check IC701, IC702

pin64: AMP_12V input.

Check output line coil.
