LG WT-R10(~3)3(7)1(3,5)TP(H) User Manual

10
3. OPERATING INSTRUCTIONS
3-1. IDENTIFICATION OF PARTS
HOT WATER SUPPLY
HOSE
COLD WATER SUPPLY
HOSE
Make sure the water
does not leak.
FUNCTION SELECTOR
Powder detergent
(powder bleach)box
for delayed washing/
softener box
Washing Tub
stainless steel tub
START/PAUSE
BUTTON
Use to start or stop the
washing machine
temporarily.
Anti Rat Base
DRAIN HOSE
For non Pump Model
• Keep downward while the
washing machine is
working.
DRAIN HOSE
For Pump Model
• Check out if the drain hose
is located in the laundry tub
before operating the washing
machine.
POWER PLUG
If the supply cord is
damaged, it must be
replaced by the manufacturer
or its service agents or
a similarly qualified person
in order to avoid a hazard.
SPIN SPE
ED
IND
IC
ATO
R
S
IL
E
N
T
C
OLD
H
OT
DELAY
W
O
O
L
N
O
R
M
AL
S
P
E
ED
Y
PRO
GRAM
START
PAUSE
POW
ER
JE
A
N
DELICATE
N
O
IN
L
E
T
D
O
O
R
O
P
E
N
D
R
A
IN
E
r
.
S
T
A
I
N
L
E
V
E
L
W
A
T
E
R
L
E
V
E
L
W
A
T
E
R
T
E
M
P
.
WASH
RINSE
MIN
MIN
MIN
SPIN
S M L XL
LIGHT
HEAVY
SOAK
DEL
AY/TIME
LE
FT
Turbo clean filter

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
