7) Water does not drain.
Where, what & how to check? Result of Check Possible Cause How to repair & settle
Drain Pump
1. Check whether there is drain pump
working sound.
2. Check resistance between terminals
if there is no working sound of the
drain pump.
3. Check connection parts of the leads
if there is no working sound and its
resistance is normal.
Drain Hose
1. Check whether the drain hose is put
in a narrow space and kinked.
2. Check whether the internal drain
rubber asm is bent.(For Non-pump
model)
3. Check whether the end of the drain
hose submerged into water or
higher than required.
(For non-pump model)
4. Check whether the drain hose is
blocked by foreign objects. It may
happen in case of the hose is a little
kinked.
PV Case
(for Non-Pump Model only)
1. Check whether the PV asm is
blocked by foreign objects.
There is pump
working sound.
Defect in
connection part.
Connection part
has no defects.
Kinked.
Bent.
Submerged or
higher than
required.
Blocked.
Blocked.
Drain pump is
blocked by foreign
objects.
It’s coil is open.
Defect in
connection part.
Defect of the
controller.
Defect of
installation.
Defect of the drain
rubber asm.
Defect of
installation.
Blocked hose.
Disassemble the drain
pump cap and remove
the foreign objects in the
pump casing.
Change the drain pump.
Repair defected
connection.
Change the controller.
Reinstall so that it should
not be kinked.
Change the drain rubber
asm.
Re-install so that it can’t
be submerged or not
higher than required.
Remove the objects and
reinstall so that it can’t be
kinked.
Separate the drain motor
from the PV link,
disassemble PV cover
and then remove the
foreign objects within
PV case.
Check the washer works
normally after repair
and reassembling them.
(PV link & drain motor
lever should be
assembled accuratel.)

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
