46
4-7. TROUBLE SHOOTING METHODS ACCORDING TO ERROR MESSAGE
For more detailed information for trouble shooting refer to page 37 to 45.
ERROR DECISION CAUSE FOR ERROR
BASIS OCCURRENCE
REMEDYERROR
• Water level does not
rise to the set level in
30 minutes.
“NO INLET”
lamp blinks
• Water is not
completely drained in
12 minutes.
“NO DRAIN”
lamp blinks
• Laundry unbalance
during spin.
“UE” display and
singnal continuously
ringing
• LID is opened in the
course of intermittent
spin, normal spin or
processing reservation .
• SIGNAL continuously
ringing.
“DOOR OPEN” lamps
blinks.
WATER
SUPPLY
DRAINAGE
UNBALANCE
DOOR
OPEN
• Water faucet is closed?
• Water supply is interrupted.
• Inlet V/V is clogged with dirts.
• Connector has bad contact to
the inlet valve.
• Natural 4 pin connector has
bad contact to the P.W.B ASM.
• Is the drain hose located
properly?
• Drain hose is folded or clogged
due to freeze or dirt.
• Bad Drain Pump part or
BLUE (WHITE) 3 pin connector to
the P.W.B ASM has bad
connection.
• Laundry in the INNER TUB is filled
unevenly.
• Washer is tilted.
• Lid is opened during
intermittent spin or normal spin?
• Lid is opened while processing
reservation?
• Connector to the Reed S/W or
RED(ORANGE or PINK) 4 pin
connector
to the P.W.B ASM has bad
connection.
• Open water faucet.
• Wait until water supply is
resumed.
• Clean or replace filter.
• Correct the connector contact.
• Same as above.
• Hung up drain hose at 0.9~1.2m
high. (For pump)
•
Put the drain hose lower (For non-pump)
• Unclose the foreign objects within
drain hose.
• Replace drain pump or correct
the connector contact.
• Try to fill laundry uniformly in the
inner tub.
• Adjust the leg.
• Closed the lid.
• Closed the lid.
• Correct the connector contact.
• Check and replace Lead Wire Asm.

LG WT-R10(~3)3(7)1(3,5)TP(H) Specifications

General

Power Sourse	Refer to rating label on the back of Washer
Input	Refer to rating label on the back of Washer
Rating of Fuse	250V, 8A for 220~240V/50Hz 125V, 12A for100~127V/60Hz
Auto Power Off	Applied
Capacity	Refer to rating label on the back of Washer
Spin Speed	710 50
Lint Filter	Double
Softener Dispenser	Applied
Detergent Dispenser	Applied
Bleach Inlet	Applied
Inner Tub	Stainless
Inlet Water Pressure	0.3kgf/cm2~ 8kgf/cm2
Water Level	7 Stages
Reservation	Available for 3 ~ 24 Hr
Program	DELICATE, WOOL, NORMAL, SPEEDY, JEAN
Lid Interlock Switch	Magnet Sensor
Child Lock	Applied

Weight and Dimensions

Dim.	Refer to rating label on the back of Washer
Weight	Refer to rating label on the back of Washer
